Collection:
Automotive Thermal Insulation and Heat Barriers
Heat insulation is a very practical solution. We insulate our houses to save energy and create more comfortable living environments. The average person spends anywhere from days to years of his or her life in a vehicle, so we’ve developed a product line to ensure your car feels like home.
Thermal insulation solves two problems: climate control inside your vehicle and heat-related issues under the hood.
By controlling the climate inside your vehicle, you can reduce the impact of the sun on a hot summer day and ensure more heat stays in your car in the winter.
Thermal barriers also help with engine related heat issues to prevent engine and exhaust heat from coming through the firewall and floorboards. Investing in floorboard insulation will keep heat out of the cabin compartment and keep you comfortable. These same materials can also be used to preserve the paint on your hood.
Second Skin’s thermal barriers and heat insulation are easy to install, economical, and will greatly increase the comfort level and enjoyment of any vehicle.
Learn the Thermal Insulation Basics Before Spending Money
Heat travels by three different methods. To keep cool, you have to redirect the heat or insulate yourself from it. Let’s take a second to learn about the types of heat, and then we’ll show you how to protect and improve your vehicle.
Conduction
Conduction of heat occurs when two objects are physically touching each other. A good example is a frying pan resting on top of a stove’s hot electric burner. The pan and burner are in physical contact, and that contact allows the transfer of heat from the stove to the frying pan. Conduction in vehicles primarily happens inside the engine.
Convection
Convection occurs when heat travels between two objects that are not physically touching. One object heats the air molecules around it, and then the hot air carries that heat to the other object, increasing its temperature. Convection is a big problem in cars, because the engine and exhaust heat transfers through the air into the cabin.
Radiation
Radiation is another problem for cars. We’re all impacted by the sun, which radiates a huge amount of heat energy to the roof, trunk lid and doors of your car. Even if there was a vacuum around your car, the energy of the sun’s heat would still travel to it via radiation. Heat also comes from inside the car, radiating from the engine block and exhaust system.
To solve heat related problems you need to:
- Reflect radiant heat away from the car’s interior, and
- Add insulation to capture as much of the remaining heat as possible
Adding automotive insulation to your vehicle can make a big difference. When applied correctly, a high quality heat shield and insulation can stop over 90% of heat transfer. You’ll literally feel the difference.
What Makes an Effective Heat Barrier?
It depends on what type of heat you’re dealing with. If it’s convection, you’re looking for an insulator with a high r-value. The r-value is going to depend on the type of material and its thickness. If you’re stopping radiant heat, you want to know what percentage of the heat the barrier will reflect.
Keep in mind that there are a ton of variables in heat transfer. It can be hard to know what to do, so we boiled it down to a few key tips:
- A heat barrier should have a smooth, metallic surface and reflect a high percentage of radiant energy (good barriers are typically 97%+). Face the barrier towards the heat source to reflect radiant heat.
- R-value, fire rating, thermal rated max temperature, and reflectivity all tell you something about how well a material insulates or reflects heat.
- Sometimes the best defense against heat is just space for airflow. The more airflow, the more heat that travels by convection is carried away.
At Second Skin, we like to use high R-value, lightweight, multi-layer materials in our vehicles.
Our Heat Wave Pro thermal insulation blanket is made by filling two strong foil outer layers with a jute material and natural cotton denim fibers. The jute and denim are treated for fire, mold, and mildew resistance. Heat Wave Pro has a Class A fire rating and meets fire resistance standards (FMVSS 302).
The reinforced foil fabric is laminated to both sides of the jute material to increase radiant reflection and add durability. The natural fibers reduce convectional heat transfer and will insulate your car from extreme temperatures. This thermal-acoustic barrier will block heat and reduce noise generated from engines, exhaust, and transmissions.
For the best results, apply Heat Wave Pro on top of our Damplifier or Damplifier Pro soundproofing material. The thick foil layer on our Damplifier products also acts as a thermal insulator and the combination will give you excellent heat control.
Need to Block Even More Heat?
For even better radiant heat reflection, we offer our Mega Block thermal insulation material, which will handle up to 1,000°F. Mega Block was specifically engineered to handle the most extreme temperature environments, even beyond what you typically see in a vehicle.
Instead of jute and denim, Mega Block uses a hydrophobic melamine foam with an aluminum foil-faced composite bonded on top. The melamine foam acts as a blanket to reduce convectional heat, and upgrading to the treated foam material greatly improves sound absorption. It’s still lightweight and flexible while being easy to install with a peel & stick backing.
Three Common Thermal Barriers
- Under the roof of your vehicle
- Under hood insulation for your vehicle
- Around the cold air intake system
Insulate Your Roof – And Stay Cool!
Remember earlier about your hot car on a summer day? To solve that problem, you need to place a layer of protection between the headliner and roof of your car. Upgrading your headliner insulation is one of the best things you can do to increase comfort in your vehicle.
Note that if you already installed a Second Skin sound deadener on the car roof, you've already added some thermal protection. If no sound deadening is present or a cheap deadener was used, you may want to add more.
Our Heat Wave Pro, the jute and denim material with foil on each side, works extremely well between the headliner and roof of a car. Besides having a very high thermal value, it also does a good job of absorbing sound. That’s a bonus, especially if your car has a great audio system.
For even better results, you could install our hydrophobic melamine foam product – it’s called Mega Zorbe. Mega Zorbe has better acoustical properties as well as a high thermal resistance. We also offer closed cell foam sheets that are a little more durable and also have a high r-value.
Insulate the Hood – Protect Your Paint
This is an absolute must if you have an expensive paint job. Otherwise, engine heat will ruin the paint several years early. First, apply our Damplifier on the metal surface of the hood, and then install Mega Block or Heat Wave Pro to reflect radiant heat. You’ll cut down on engine noise, while making the top of your hood cool to the touch.
Insulate the Cold Air Intake – Increase Engine Performance
Cold air intake systems are made of plastic. The problem is, plastic easily allows engine compartment heat to warm the air inside the cold air tract, defeating its purpose. To combat that, and give your engine a breath of cool, dense air, with an air intake heat shield. Protect the cold air intake tract with some Thermal Block.
Second Skin Can Help!
Each project is different. Let us apply our years of experience to help you find the right product for the job. We’re happy to talk through any project with anyone who calls in. We've seen thousands of jobs – let us save you some time. Second Skin is here to help!
Any vehicle that rattles or shakes, and most do, can benefit from sound deadening. Whether you installed a high-end sound system, are fixing up a hot rod, or just want to carve out a little bubble of comfort for your drive to work, Second Skin's sound deadening are best in class. Join Team Second Skin and turn any car into a luxury vehicle!
