Cargo Van Insulation Packages
Create a quieter, better-insulated cargo van interior with the Second Skin Cargo Van Insulation Package — featuring your choice of premium insulation materials for van walls, ceilings, and rear doors. Choose from Mega Zorbe™, Heat Wave Pro™, 3M™ Thinsulate™, or 2" EcoVerb™ Roll to match your sizing and acoustic and thermal needs. Whether you're building out a camper van or work rig, this package delivers proven performance and reliable comfort. For even greater noise reduction, add Damplifier Pro™ sound deadening mats to the package.
Features
- Select the premium insulation option that suit your needs
- Exceptional noise and thermal control for improved interior comfort
- Moisture-resistant materials for long-term durability
- Designed to cover all popular cargo van makes and models for walls, ceiling, and rear doors
- Add Damplifier Pro™ for maximum noise reduction
- Proudly made in the USA
Couldn't load pickup availability
Van Insulation Package Options
Van Insulation Package Options
Which Package is Best for Me?
| Insulation | R-Value per Inch | NRC | Why this Insulation? |
| Mega Zorbe™ | 4.16 | 0.40 | Super lightweight with peel & stick backing for easy install |
| Heat Wave Pro™ | 3.91 | 0.45 | Recycled acoustic insulation with a reflective heat barrier |
| 3M™ Thinsulate™ SM600L | 3.50 | 0.85 | Cost-effective and lightweight sound and thermal insulation |
| EcoVerb™ Acoustic Roll | 4.00 | 1.15 | Extremely absorptive and easy to work with |
What's in the Package?
| Insulation Included | 115" | 135" | 155" |
| Mega Zorbe™ (sheets) | 36 | 40 | 48 |
| Heat Wave Pro™ (sheets) | 6 | 7 | 8 |
| 3M™ Thinsulate™ SM600L (linear feet) | 30 | 35 | 40 |
| EcoVerb™ Roll (linear feet) | 35 | 40 | 45 |
| 22oz Cans of P329 Spray Adhesive | 6 | 7 | 8 |
*Mega Zorbe has a peel & stick backing for install. All other packages come with P329 Spray Adhesive
Damplifier Pro Matters - Here's Why!
Damplifier Pro™ is a premium sound deadening mat with an effective constrained layer for maximum damping.
Just 30% coverage with Damplifier Pro is better than 100% coverage with a low-quality mass-loading mat!
| Damplifier Pro™ (12" x 20") | Noise Reduction |
| 30% Coverage | 3-5 dB |
| 60% Coverage | 5-7 dB |
| 100% Coverage | 7-10 dB |
| Damplifier Pro™ Sheets | 115" | 135" | 155" |
| 30% Coverage | 26 | 30 | 36 |
| 60% Coverage | 52 | 60 | 72 |
| 100% Coverage | 86 | 94 | 114 |
Material Testing
Material Testing
Noise Reduction Coefficient
| Frequency (Hz) | 125 | 250 | 500 | 1000 | 2000 | 4000 | NRC |
| Mega Zorbe | 0.11 | 0.12 | 0.25 | 0.42 | 0.77 | 0.94 | 0.40 |
| Heat Wave Pro | 0.12 | 0.10 | 0.23 | 0.56 | 0.81 | 0.89 | 0.45 |
| 3M Thinsulate SM600L | 0.18 | 0.44 | 0.96 | 1.10 | 0.98 | 0.90 | 0.85 |
| EcoVerb Roll 2" | 0.35 | 0.94 | 1.32 | 1.22 | 1.06 | 1.03 | 1.15 |
| Tested Properties | Testing Method | Performance |
|---|---|---|
| R-Value per Inch | ASTM C518 | Mega Zorbe: 4.16 |
| Fire Rating | ASTM E84 | Mega Zorbe: Class A |
Product FAQs
| Wheelbase | Mega Zorbe (sheets) | Heat Wave Pro (sheets) | 3M Thinsulate SM600L (linear ft) | EcoVerb Roll (linear ft) | P329 Spray Adhesive (cans) |
| 115" Wheelbase (Small) | 36 | 6 | 30 | 35 | 6 |
| 135" Wheelbase (Medium) | 40 | 7 | 35 | 40 | 7 |
| 155" Wheelbase (Large) | 48 | 8 | 40 | 45 | 8 |
| Insulation | Thickness | R-value (per inch) | NRC | Why this insulation? |
| 3M Thinsulate SM600L | 1-1/2" | 3.5 | 0.85 | Budget-friendly, with up to 2x the warmth of traditional insulation. |
| Heat Wave Pro | 3/8" | 3.91 | 0.45 | Low profile and compressible. Works best with an air gap. |
| EcoVerb Roll | 2" | 4.0 | 1.15 | Our recycled cotton option, with the most sound absorption. |
| Mega Zorbe | 1/2" | 4.16 | 0.40 | Easiest install: peel-and-stick, no spray adhesive needed. |
| Setup | Expected Reduction |
| Insulation only | 3 to 5 dB |
| Insulation + Damplifier Pro, 30% coverage | 5 to 7 dB |
| Insulation + Damplifier Pro, 60% coverage | 7 to 10 dB |
| Insulation + Damplifier Pro, 100% coverage | 10+ dB |
| Insulation | Fire rating | Test |
| 3M Thinsulate SM600L | Pass (Self-extinguishing) | FMVSS 302, ISO 3795, DIN 75200 |
| Heat Wave Pro | Exceeds Standard (Less than 1/5 in./min) | FMVSS 302 |
| EcoVerb Roll | Class A | ASTM E84 |
| Mega Zorbe | Class A; V-0 | ASTM E84; UL 94 |
| Material | How it attaches | Install guide |
| 3M Thinsulate SM600L | P329 spray adhesive, included | 3M Thinsulate install guide |
| Heat Wave Pro | P329 spray adhesive, included | Heat Wave Pro install guide |
| EcoVerb Roll | P329 spray adhesive, included | EcoVerb Roll install guide |
| Mega Zorbe | Peel-and-stick backing | Mega Zorbe install guide |
| Damplifier Pro (optional add-on) | Peel-and-stick butyl backing | Damplifier Pro install guide |
