BlocknZorbe™ Multi-Purpose Sound Panels
In stock. This product ships in 1-3 business days.
Square Footage Calculator
BlocknZorbe™ Multi-Purpose Sound Panels
BlocknZorbe™ is our most versatile acoustical panel. We call it our "utility player" because it is an awesome solution for many projects that are more difficult to solve. Whether you need UV resistant, waterproof, durable, non-fibrous, or easy to clean, BlocknZorbe™ is that tough-minded friend you'll be glad is in your corner!
Features
- Semi-rigid, porous expanded polypropylene sound panels are the only acoustical panels to both BLOCK and ABSORB noise
- Install directly on walls or ceilings
- Waterproof, impact resistant, and tack-able
- Use indoors or outdoors (Charcoal)
- Class A Fire Rated
- Non-fibrous and easy to clean
- Proudly made in the USA
Couldn't load pickup availability
Specs
Specs
| Dimensions | 24" x 24", 24" x 48" |
| Thickness | 1", 2" |
| Weight | 24" x 24" x 1": 1 lb |
| Edge Type | Square Edge |
| Colors | Charcoal (outdoor), White |
| Temperature Rating | 230°F |
| R-value | 3.8 per inch |
| Paintable | Yes, spray light coats |
Material Testing
Material Testing
Noise Reduction Coefficient
| Frequency (Hz) | 125 | 250 | 500 | 1000 | 2000 | 4000 | NRC |
| 1" BlocknZorbe™ Sound Panel | 0.05 | 0.06 | 0.21 | 0.80 | 0.65 | 0.75 | 0.45 |
| 2" BlocknZorbe™ Sound Panel | 0.07 | 0.21 | 0.81 | 0.85 | 0.93 | 0.88 | 0.70 |
Sound Transmission Loss
| Frequency (Hz) | 125 | 250 | 500 | 1000 | 2000 | 4000 | STC |
| 1" BlocknZorbe™ Sound Panel | 6 | 5 | 7 | 8 | 10 | 15 | 9 |
| 2" BlocknZorbe™ Sound Panel | 9 | 8 | 10 | 10 | 17 | 22 | 13 |
| Tested Properties | Testing Method | Performance |
|---|---|---|
| Fire Rating | ASTM E84 | Class A |
| Fungal Growth | ASTM C1338 | Pass |
| R-value | ASTM C177 | 3.8 per inch |
| VOC | CDPH Standard Method v1.2 | Pass |
| Light Reflectance | ASTM E1477 | 90 (White) |
Common Product Uses
Common Product Uses
Install Instructions
Install Instructions
- Recommended Installation: Mechanically fasten with screws
- The easiest way to install BlocknZorbe™ sound panels is to screw them into drywall, wood, metal, or concrete. All screws should be at least 3/4" from the edge of the panel.
- Our recommended adhesives can be used as an optional installation method
- If field cuts are needed, use a table saw. Set blade to cut half the thickness of the BlocknZorbe™ acoustic material. (i.e. for a 2" thick panel, cut 1" and then flip the panel over and cut 1" again to complete the cut)
- These steps can be found in the BlocknZorbe™ Install Guides: (Direct Attach).
BlocknZorbe can also be installed with adhesive. We offer the P329 Spray Adhesive (BlocknZorbe™ Install Guide (P329 Spray Adhesive)) or adhesive can be bought locally (BlocknZorbe™ Install Guide (Construction Adhesive)).
Screw Recommendations
| Panel Thickness | Substrate | Rec. Screw Type | Rec. Screw Length |
|---|---|---|---|
| 1" | Hat Channel or Thin Metal | Self-Tapping | 2" |
| 1" | Drywall or Wood Furring | Drywall Screw | 1-5/8" |
| 1" | Concrete | Tapcon | 2-1/4" |
| 2" | Hat Channel or Thin Metal | Self-Tapping | 3" |
| 2" | Drywall or Wood Furring | Drywall Screw | 3" |
| 2" | Concrete | Tapcon | 3-1/4" |
