BlocknZorbeâ„¢ Acoustic Baffles
In stock. This product ships in 1-3 business days.
Regular price
$89.99
Sale price
Regular price
Square Footage Calculator
BlocknZorbeâ„¢ Acoustic Baffles
BlocknZorbeâ„¢ acoustic ceiling baffles are one of the most durable and lightweight acoustic baffle options out there! These non-fibrous, easy to clean panels are also easy to install and provide excellent sound absorption and noise control! BlocknZorbeâ„¢ acoustic baffles are a great alternative to fiberglass and other fibrous options!
Features
- Semi-rigid, porous expanded polypropylene beads
- Comes with 2 corkscrew hangers
- Easy to install using light duty cable or chain
- Lightweight and easy to clean
- Water resistant and impact resistant
- Class A Fire Rated
- Proudly made in the USA
Couldn't load pickup availability
Specs
Specs
| Dimensions | 24" x 48" |
| Thickness | 1", 2" |
| Weight | 2lbs (1"), 4lbs (2") |
| Edge Type | Square Edge |
| Colors | Charcoal, White |
| Paintable | Yes, spray light coats |
Material Testing
Material Testing
Sabins per Baffle
| Panel Type | Thickness | Mount Type | 125 | 250 | 500 | 1000 | 2000 | 4000 | Sabins/Baffle |
| BlocknZorbeâ„¢ Acoustic Baffle | 1" | 16" spacing | 0.82 | 2.18 | 2.79 | 3.03 | 6.29 | 8.36 | 3.55 |
| BlocknZorbeâ„¢ Acoustic Baffle | 2" | 16" spacing | 1.17 | 2.53 | 3.67 | 6.61 | 9.39 | 10.64 | 5.55 |
| Tested Properties | Testing Method | Performance |
|---|---|---|
| Acoustical Performance | ASM C423-17 (16" Spacing) | 3.55 to 5.55 Sabins/Baffle |
| Fire Rating | ASTM E84 | Class A |
| Fungal Growth | ASTM C1338 | Pass |
| VOC | CDPH Standard Method v1.2 | Pass |
| Light Reflectance | ASTM E1477 | 90 (White) |
Installation Instructions
Installation Instructions
Recommended Attachment: Corkscrew (included), light duty chain (by other)
- Screw the provided corkscrew into the BlocknZorbeâ„¢ panel until only the eyelet is visible.
- Loop suspension cable (provided by other) into the eyelet on the corkscrew and close the loop with a cable clamp or similar hardware.
- Suspension cable should be anchored to the roof deck or ceiling structure.
Check out our full install guide !
Common Product Uses
Common Product Uses
- Offices, gymnasiums, auditoriums, schools, classrooms, cafeterias, manufacturing plants, and warehouses, homes, skating rinks, dog kennels.
- Also sold as EZ drop ceiling tiles: BlocknZorbeâ„¢ EZ Drop.
Resources
Installation Guides
Spec Sheets
Architect CSI Specs
